9 Band Portable Radio Receiver 3559

Elta GmbH, Rödermark

  • Year
  • 1997
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 166113

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
  • Power type and voltage
  • Dry Batteries / 3 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
  • Power out
  • 0.2 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: 9 Band Portable Radio Receiver 3559 - Elta GmbH, Rödermark
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 150 x 90 x 33 mm / 5.9 x 3.5 x 1.3 inch
  • Notes
  • 6 Kurzwellenbereiche, Kopfhöreranschluß über Klinkenbuchse 3,5 mm, FM/SW-Teleskopantenne 50 cm, MW/LW-eingebaute Ferritantenne.
  • Net weight (2.2 lb = 1 kg)
  • 0.3 kg / 0 lb 10.6 oz (0.661 lb)
