Dioden-Transistor-Testgerät TT7000

Dioden-Transistor-Testgerät TT7000; ELV Elektronik AG; (ID = 1295733) Equipment

Dioden-Transistor-Testgerät TT7000; ELV Elektronik AG; (ID = 1295737) Equipment

Dioden-Transistor-Testgerät TT7000; ELV Elektronik AG; (ID = 1295740) Equipment

Dioden-Transistor-Testgerät TT7000; ELV Elektronik AG; (ID = 1295741) Equipment

Dioden-Transistor-Testgerät TT7000; ELV Elektronik AG; (ID = 1295742) Equipment

Dioden-Transistor-Testgerät TT7000; ELV Elektronik AG; (ID = 1295743) Equipment

Dioden-Transistor-Testgerät TT7000; ELV Elektronik AG; (ID = 1295744) Equipment
Dioden-Transistor-Testgerät TT7000; ELV Elektronik AG; (ID = 1197409) Equipment
Use red slider bar for more.
Dioden-Transistor-Testgerät TT7000; ELV Elektronik AG; (ID = 1197409) Equipment
ELV Elektronik AG;: Dioden-Transistor-Testgerät TT7000 [Equipment] ID = 1197409 929x441
Select picture or schematic to display from thumbnails on the right and click for download.
For model Dioden-Transistor-Testgerät TT7000, ELV Elektronik AG; Leer (Ostfriesland):
Dioden-Transistor-Testgerät TT7000

Country:  Germany
Manufacturer / Brand:  ELV Elektronik AG; Leer (Ostfriesland)
Year: 1981 Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) Semiconductors present. ICL7107 TL081 TL082 µA78xx µA79xx 1N4001 1N4007 1N4148 ZPD5,6 BF472 TIP140
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 230 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Dioden-Transistor-Testgerät TT7000 - ELV Elektronik AG; Leer
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 260 x 75 x 150 mm / 10.2 x 3 x 5.9 inch
Notes

ELV TT7000. Dioden- und Transistortestgerät mit 3 1/2stelliger digitaler Anzeige. Bis zu 200 V Kollektor-Emitter Testspannung. Halbleiter können mehrfach vorhanden sein.

Mentioned in - - Manufacturers Literature (Beschreibung in ELV-Heft 16/1981)

Model page created by Gerhard Heigl. See "Data change" for further contributors.
