520 Ch= 120029 gold dial 180°, octal tubes
Emerson Radio & Phonograph Corp.; New York, NY
- Country
- United States of America (USA)
- Manufacturer / Brand
- Emerson Radio & Phonograph Corp.; New York, NY
- Year
- 1946
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 38532
-
- alternative name: Emerson Television
Picture courtesy of Judy Kocher
eBay seller dkallencat1.
my 1940 emerson catalin radio model 520
eBay seller dkallencat1.
eBay seller dkallencat1.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- AC/DC-set / 105-125 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4.5 inch = 11.4 cm
- Material
- Catalin (a brand name for a thermosetting polymer popular in the 1930s and 1940s - a phenol formaldehyde resin - like Bakelite, but a two-stage process with a lot of work afterwards).
- from Radiomuseum.org
- Model: 520 Ch= 120029 [gold dial 180°, octal tubes] - Emerson Radio & Phonograph
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 11 x 8 x 6.5 inch / 279 x 203 x 165 mm
- Notes
- BC Band Tuning Range: 540-1620kHz. Built-in loop antenna. Chassis No.120029 has a 180° dial and metal or glass octal tubes. Ivory speaker grille with square or round holes.
- Net weight (2.2 lb = 1 kg)
- 3.8 kg / 8 lb 5.9 oz (8.37 lb)
- Price in first year of sale
- 35.00 $
- External source of data
- Ernst Erb
- Circuit diagram reference
- Rider's Perpetual, Volume 16 = ca. 1948 and before
- Mentioned in
- Sideli: Classic Plastic Radios of the 1930´s and 1940´s
- Literature/Schematics (1)
- Radio Retailing (Radio & Television R.) (May 1946 page 97.)
- Literature/Schematics (2)
- Emerson Radio and Television Service Manual (Page 11)
