- Country
- United States of America (USA)
- Manufacturer / Brand
- Emerson Radio & Phonograph Corp.; New York, NY
- Year
- 1947/1948 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 347205
-
- alternative name: Emerson Television
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Line / Batteries (any type) / 105-125 / 4.5 & 67.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 559B - Emerson Radio & Phonograph
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 9 x 8 x 5 inch / 229 x 203 x 127 mm
- Notes
-
Similar to the 1947/1948 Emerson 559A except that the output tube is type 3V4.
- Author
- Model page created by Jay Kinnard. See "Data change" for further contributors.
