For model 898B Ch= 120456B, Emerson Radio & Phonograph Corp.; New York, NY:
Sams Photofact Folders

Country:  United States of America (USA)
Manufacturer / Brand:  Emerson Radio & Phonograph Corp.; New York, NY
alternative name

Emerson Television
Year: 1959 Category: Sound/Video Recorder and/or Player
Valves / Tubes 3: 12AX7 50EH5 50EH5
Main principle Audio-Amplification
Wave bands - without
Details Rec.Player+Audio.Amp+LS
Power type and voltage Alternating Current supply (AC) / 110 - 120 Volt
Loudspeaker 2 Loudspeakers / Ø 4 inch = 10.2 cm
Power out
from Radiomuseum.org Model: 898B Ch= 120456B - Emerson Radio & Phonograph
Shape Tablemodel, with any shape - general.
Notes The Emerson Model 898B is an AC operated 3 Tube Phono Amplifier with 4 Speed Automatic Record Changer.
Circuit diagram reference Beitman Radio Diagrams Vol. 19, 1959
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Date 10-59, Set 458, Folder 8)

Model page created by Hinrich Grensemann † 15.5.16. See "Data change" for further contributors.
