AR-173 Ch= AR Push-pull audio

AR-173 Ch= AR; Emerson Radio & (ID = 283224) Radio

AR-173 Ch= AR; Emerson Radio & (ID = 569983) Radio
AR-173 Ch= AR; Emerson Radio & (ID = 1412789) Radio AR-173 Ch= AR; Emerson Radio & (ID = 1412790) Radio
AR-173 Ch= AR; Emerson Radio & (ID = 2064883) Radio
Use red slider bar for more.
AR-173 Ch= AR; Emerson Radio & (ID = 1412789) Radio
Emerson Radio &: AR-173 Ch= AR [Radio] ID = 1412789 800x519
Select picture or schematic to display from thumbnails on the right and click for download.
For model AR-173 Ch= AR Push-pull audio, Emerson Radio & Phonograph Corp.; New York, NY:
Scanned from the Emerson Folder Form. 38-3, 5-37 for 1938.

Country:  United States of America (USA)
Manufacturer / Brand:  Emerson Radio & Phonograph Corp.; New York, NY
alternative name

Emerson Television
Year: 1937/1938 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6A7 6D6 6Q7 41 41 80
Main principle Super-Heterodyne (Super in general); ZF/IF 456 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 6.5 inch = 16.5 cm
Power out 5 W (unknown quality)
from Radiomuseum.org Model: AR-173 Ch= AR [Push-pull audio] - Emerson Radio & Phonograph
Material Wooden case
Shape Tablemodel, low profile (big size).
Notes

Serials 1326200-1412601. BC (540-1730kHz) and SW (5.6-18.0MHz) bands. 6.5" or 10" speaker. The cabinet was made with contrasting figured Walnut the "Miracle Tone Chamber."

Price in first year of sale 49.95 $
Circuit diagram reference Rider's Perpetual, Volume 9 = 1938 and before
Literature/Schematics (3) Emerson Folder Form. 38-3, 5-37 for 1938.
