AX-221-AC-DC

AX-221-AC-DC ; Emerson Radio & (ID = 1409904) Radio

AX-221-AC-DC ; Emerson Radio & (ID = 1409907) Radio
AX-221-AC-DC ; Emerson Radio & (ID = 1412599) Radio AX-221-AC-DC ; Emerson Radio & (ID = 1412600) Radio
Use red slider bar for more.
AX-221-AC-DC ; Emerson Radio & (ID = 1412599) Radio
Emerson Radio &: AX-221-AC-DC [Radio] ID = 1412599 750x747
Select picture or schematic to display from thumbnails on the right and click for download.
For model AX-221-AC-DC, Emerson Radio & Phonograph Corp.; New York, NY:
Scanned from the Emerson Folder Form. 39-22, 2-39 for 1939.

Country:  United States of America (USA)
Manufacturer / Brand:  Emerson Radio & Phonograph Corp.; New York, NY
alternative name

Emerson Television
Year: 1938/1939 Category: Broadcast Receiver - or past WW2 Tuner
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details Record Player (perh.Changer)
Power type and voltage AC/DC-set / 105-125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6.5 inch = 16.5 cm
Power out
from Radiomuseum.org Model: AX-221-AC-DC - Emerson Radio & Phonograph
Material Wooden case
Shape Tablemodel, Box - most often with Lid (NOT slant panel).
Notes

Separate AX-221-AC model available. Ingraham cabinet.

Price in first year of sale 54.95 $
Literature/Schematics (3) Emerson Folder Form. 39-22, 2-39 for 1939.

Model page created by Ernst Erb. See "Data change" for further contributors.
