FM/AM Digital Clock Radio RED5511

Emerson Radio & Phonograph Corp.; New York, NY

Data
Forum
Pictures
Collections

  • Year
  • 1985 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 253606
    • alternative name: Emerson Television

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 120 / 1 x 9 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: FM/AM Digital Clock Radio RED5511 - Emerson Radio & Phonograph
  • Shape
  • Tablemodel with Clock ((Alarm-) Clock Radio).
  • Dimensions (WHD)
  • 8.25 x 2 x 5 inch / 210 x 51 x 127 mm
  • Notes

  • Emerson Table Top 2-Band Alarm Clock Radio Model RED5511.
    Tuning Range: AM 540 - 1600 kHz, FM 88 - 108 MHz
    Power Consumption 6 Watts.
    Battery Backup (1 x 9V)
    Molded Plastic Cabinet Finished To Simulate Walnut Grain.
    Made in Hong Kong.

  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
