Emerson Radio &: 988 "Rambler" Ch= 120485 [Radio] ID = 2223746 1200x1600
Select picture or schematic to display from thumbnails on the right and click for download.
For model 988 'Rambler' Ch= 120485, Emerson Radio & Phonograph Corp.; New York, NY

Country:  United States of America (USA)
Manufacturer / Brand:  Emerson Radio & Phonograph Corp.; New York, NY
alternative name

Emerson Television
Year: 1960 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8: 2N485 2N485 2N483 2N483 2N363 2N363 2N633 2N633
Main principle Superheterodyne (common); ZF/IF 455 kHz; 3 AF stage(s)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 988 "Rambler" Ch= 120485 - Emerson Radio & Phonograph
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 6.5 x 4 x 2 inch / 165 x 102 x 51 mm
Mentioned in -- Collector info (Sammler)
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Date October 1960, Set 502, Folder 8)

Model page created by Peter Hoddow. See "Data change" for further contributors.
