Radiotélefono portátil VHF EN-303

Ensa, Electrónica Ensa, S.A.; Alcobendas (Madrid)

  • Year
  • 1970
  • Category
  • Commercial Transmitter & Receiver (TRX not Amateur)
  • Radiomuseum.org ID
  • 314968

 Technical Specifications

  • Number of Transistors
  • 37
  • Main principle
  • Superhet, double/triple conversion; ZF/IF 10700/100 kHz
  • Tuned circuits
  • 5 FM circuit(s)
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 8 x 1,25 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
  • Power out
  • 0.25 W (max.)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Radiotélefono portátil VHF EN-303 - Ensa, Electrónica Ensa, S.A.;
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 220 x 90 x 190 mm / 8.7 x 3.5 x 7.5 inch
  • Notes
  • Electrónica Ensa S.A. EN-303

    Radioteléfono portátil de VHF-FM. hasta 6 canales a cristal de cuarzo en una de las tres bandas de VHF, Baja de 29,5 a 50  MHz, Media de 66 a 87,5 MHz y Alta de 146 a 174 MHz

    Potencia de salida 1W RF.
