For model 16A alternatif, Erga; Namur

Country:  Belgium
Manufacturer / Brand:  Erga; Namur
Year: 1937–1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6A7 6D6 75 6L6G 80
Main principle Super-Heterodyne (Super in general); 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 130; 140; 220; 240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 17 cm = 6.7 inch
Power out 3 W (unknown quality)
from Radiomuseum.org Model: 16A [alternatif] - Erga; Namur
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 550 x 340 x 250 mm / 21.7 x 13.4 x 9.8 inch
Notes

This model was made with the chassis from SBR Super Ondolina 384A. The 7th tuned circuit (RF pre-filter) is deactivated when receiving shortwaves.

Price in first year of sale 1'750.00 BEF
Mentioned in -- Original prospect or advert (Programme 1938, Programme 1939)

Model page created by Leo Snoeren. See "Data change" for further contributors.



All listed radios etc. from Erga; Namur
Here you find 12 models, 10 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
