• Country
• Netherlands

• Manufacturer / Brand
• Erres, Van der Heem NV; Den Haag

• Year
• 1978

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 166443

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 110 - 127; 220 - 240 / C: 5 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch

• Power out
• 1 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Cassettenrecorder EK-3218 - Erres, Van der Heem NV; Den

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 200 x 65 x 340 mm / 7.9 x 2.6 x 13.4 inch

• Net weight (2.2 lb = 1 kg)
• 1.7 kg / 3 lb 11.9 oz (3.744 lb)

• Mentioned in
• -- Original prospect or advert

• Author
• Model page created by Bernd Pötzsch. See "Data change" for further contributors.
