RS2233

RS2233; Erres, Van der Heem (ID = 1217360) Radio RS2233; Erres, Van der Heem (ID = 1217361) Radio
RS2233; Erres, Van der Heem (ID = 1217362) Radio RS2233; Erres, Van der Heem (ID = 1217363) Radio
RS2233; Erres, Van der Heem (ID = 1217364) Radio RS2233; Erres, Van der Heem (ID = 1217366) Radio
RS2233; Erres, Van der Heem (ID = 1217368) Radio RS2233; Erres, Van der Heem (ID = 1217369) Radio
Use red slider bar for more.
RS2233; Erres, Van der Heem (ID = 1217360) Radio
Erres, Van der Heem: RS2233 [Radio] ID = 1217360 800x312
Select picture or schematic to display from thumbnails on the right and click for download.
For model RS2233, Erres, Van der Heem NV; Den Haag

Country:  Netherlands
Manufacturer / Brand:  Erres, Van der Heem NV; Den Haag
Year: 1972 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10:
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 1.5 W (unknown quality)
from Radiomuseum.org Model: RS2233 - Erres, Van der Heem NV; Den
Material Plastics (no bakelite or catalin)
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 500 x 165 x 145 mm / 19.7 x 6.5 x 5.7 inch
Notes

Die Erres RS2233 ist eine Export-Ausführung des Modelles Apart 6400 von Hersteller VEB Stern-Radio Sonneberg.
Skala und Rückwand zeigen den Namen "ERRES" auf.
Lautsprecher VEB Stern-Radio Typ L2201, 3W 8 Ohm.

Net weight (2.2 lb = 1 kg) 3.5 kg / 7 lb 11.3 oz (7.709 lb)
Source of data - - Data from my own collection

Model page created by Maurice Hamm. See "Data change" for further contributors.
