Sky Master ; Ever Ready Co. GB (ID = 186786) Radio
Ever Ready Co. GB: Sky Master [Radio] ID = 186786 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Sky Master Early, Ever Ready Co. (GB) Ltd.; London:
A mid 1960s Ever Ready Sky Master MW/LW radio in a blue rexine covered wooden case complete with its shoulder strap.

Country:  Great Britain (UK)
Manufacturer / Brand:  Ever Ready Co. (GB) Ltd.; London
Year: 1962 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: AF117 AF117 AF117 OC81D OC81 OC81
Main principle Superheterodyne (common); ZF/IF 470 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3 inch = 7.6 cm
Power out 0.5 W (unknown quality)
from Radiomuseum.org Model: Sky Master [Early] - Ever Ready Co. GB Ltd.; London
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 8.5 x 6.75 x 3 inch / 216 x 171 x 76 mm
Notes Released October 1962, price £13 17s 0d plus purchase tax.
Net weight (2.2 lb = 1 kg) 1.3 kg / 2 lb 13.8 oz (2.863 lb)
Price in first year of sale 14.00 GBP
Source of data - - Data from my own collection
Circuit diagram reference Radio and TV Servicing books (R&TVS) book
Mentioned in Wireless and Electrical Trader
Literature/Schematics (1) Trader Sheet 1589

Model page created by Howard Craven. See "Data change" for further contributors.



All listed radios etc. from Ever Ready Co. (GB) Ltd.; London
Here you find 204 models, 144 with images and 91 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
