• Country
• United States of America (USA)

• Manufacturer / Brand
• Exact Electronics Inc.; Hillsboro (OR)

• Year
• 1973

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 185091

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Power type and voltage
• Alternating Current supply (AC) / 115 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: AM/FM Function-Generator 129 - Exact Electronics Inc.;

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 12.5 x 3.5 x 10.5 inch / 318 x 89 x 267 mm

• Notes

• For further details, see technical documentation.

• Mentioned in
• -- Original prospect or advert (Electronic Design, March 15, 1973, page 39)

• Author
• Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
