Militarized Portascope 765MH
Fairchild Camera and Instrument Corp.; Clifton, N.J.
- Country
- United States of America (USA)
- Manufacturer / Brand
- Fairchild Camera and Instrument Corp.; Clifton, N.J.
- Year
- 1965
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 250571
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- F7660-0-P31
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 115; 230 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Special material, described in the notes.
- from Radiomuseum.org
- Model: Militarized Portascope 765MH - Fairchild Camera and
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 450 x 209 x 584 mm / 17.7 x 8.2 x 23 inch
- Notes
-
The basic indicator houses the CRT, power supplies and has 2 cavities into which various X and Y plug-ins may be inserted like Delaying Sweep Type 74-11A und
Dual Trace Type 76-08. All electrical specifications are identical to 765H Series.Case and covers are constructed of rugged fiberglas material. An RFI metalic coating is sprayed inside the case.
The weight with plug-ins is less than 35 pounds = 15,8 kg
- Net weight (2.2 lb = 1 kg)
- 27 lb (27 lb 0 oz) / 12.258 kg
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Heribert Jung. See "Data change" for further contributors.
