For model 621SL, Familial Radio, G. Dubois; Fourmies, Paris, Glageon

Country:  France
Manufacturer / Brand:  Familial Radio, G. Dubois; Fourmies, Paris, Glageon
Year: 1942 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH3 EBF2 EF9 EL3N EM4 1883
Main principle Superheterodyne (common); ZF/IF 472 kHz
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
Power out 4.5 W (unknown quality)
from Radiomuseum.org Model: 621SL - Familial Radio, G. Dubois;
Material Bakelite case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 496 x 290 x 265 mm / 19.5 x 11.4 x 10.4 inch
Notes

6 gammes d'ondes :

  • OC1 de 13 à 21 m
  • OC2 de 20 à 23 m
  • OC3 de 32 à 52 m
  • PO1 de 190 à 330 m
  • PO2 de 320 à 585 m
  • GO de 1100 à 1950 m
Net weight (2.2 lb = 1 kg) 15 kg / 33 lb 0.6 oz (33.04 lb)
External source of data Serge Laffont/Martin Renoth
Mentioned in Schémathèque Toute la Radio (STR) (No. 584)
