BK-84 (is BKR-84?)

BK-84 ; Farnsworth (ID = 339107) Radio
Use red slider bar for more.
BK-84 ; Farnsworth (ID = 339107) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  Farnsworth Television & Radio Corp. - see also Capehart
Year: 1940/1941 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: 6SK7 6J5GT 6SA7 6SK7 6SQ7 6K6GT 6X5GT
Main principle Superhet with RF-stage; ZF/IF 455 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Loudspeaker
Power out
from Radiomuseum.org Model: BK-84 - Farnsworth Television & Radio
Notes

Only mentioned in Riders without a schematic. Probably it should read BKR84. No evidence otherwise for this model.

External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 13 = 1942 and before
Literature/Schematics (1) Rider's Perpetual, Volume 13 = 1942 and before (p.13-17)
