Capehart-Panamuse Regency 15M4 Ch= M4

Capehart-Panamuse Regency 15M4 Ch= M4; Farnsworth (ID = 1288782) Radio

Capehart-Panamuse Regency 15M4 Ch= M4; Farnsworth (ID = 1288783) Radio

Capehart-Panamuse Regency 15M4 Ch= M4; Farnsworth (ID = 1288785) Radio

Capehart-Panamuse Regency 15M4 Ch= M4; Farnsworth (ID = 1288784) Radio
Capehart-Panamuse Regency 15M4 Ch= M4; Farnsworth (ID = 1286409) Radio Capehart-Panamuse Regency 15M4 Ch= M4; Farnsworth (ID = 1286411) Radio
Capehart-Panamuse Regency 15M4 Ch= M4; Farnsworth (ID = 1286415) Radio Capehart-Panamuse Regency 15M4 Ch= M4; Farnsworth (ID = 1286417) Radio
Capehart-Panamuse Regency 15M4 Ch= M4; Farnsworth (ID = 1286418) Radio Capehart-Panamuse Regency 15M4 Ch= M4; Farnsworth (ID = 1481227) Radio
Use red slider bar for more.
Capehart-Panamuse Regency 15M4 Ch= M4; Farnsworth (ID = 1286409) Radio
Farnsworth: Capehart-Panamuse Regency 15M4 Ch= M4 [Radio] ID = 1286409 500x742
Select picture or schematic to display from thumbnails on the right and click for download.
For model Capehart-Panamuse Regency 15M4 Ch= M4, Farnsworth Television & Radio Corp. - see also Capehart:
Folder Capehart Panamuse with the non turning Panamuse Record changer model "Regency". The model was available at least with two different woods.

Country:  United States of America (USA)
Manufacturer / Brand:  Farnsworth Television & Radio Corp. - see also Capehart
Year: 1941/1942 perfect model Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 11: 6SK7 6J5GT 6SA7 6SK7 6J5GT 6J5GT 6SQ7 6SQ7 6V6G 6V6G 5Y3G
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Wave bands Broadcast plus 2 Short Wave bands.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 112 watts, 105 - 125 = 117 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
Power out 10 W (unknown quality)
from Radiomuseum.org Model: Capehart-Panamuse Regency 15M4 Ch= M4 - Farnsworth Television & Radio
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 20 x 35.3 x 17 inch / 508 x 897 x 432 mm
Notes The model Capehart-Panamuse Regency 15-M-4 and 20th Century 16-M-4 share the same schematic and exist for AM only. They have only one chassis - with 11 tubes, receiving BB, SW and Band spread. See details and summaries in this common text for Capehart Deluxe Radio-Phonographs. Post 3 is specific for this last pre war model family.

11-tube AM chassis including amplifier: 6SK7 RF, 6J5 oscillator, 6SA7 mixer, 6SK7 1st IF, 6J5 det., 6J5 AVC, 6SQ7 audio, 6SQ7 inverter, 6V6GT, 6V6GT, 5Y3G. See Rider's Capehart-Farnsworth page 20-17 to 20-20. The changer P-62 is the Panamuse changer with the two record support posts, instructions etc. are found at Rider's RCD. CH page Farnsworth 18-10 to 18-24.
Mentioned in Rider's Perpetual, Volume 20 = covering 1950 (Capehart, series M-4, page 20-17 to 20-20)

Model page created by Ernst Erb. See "Data change" for further contributors.
