• Country
• Finland

• Manufacturer / Brand
• Fenno, Helsinki - see also Philips

• Year
• 1964 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 185218

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 9

• Semiconductors
• AF124 AF125 AF126 AF126 AF126 AC125 AC126 AC128 AC128

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Dry Batteries / 5 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: F453PT/40G - Fenno, Helsinki - see also

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 250 x 160 x 70 mm / 9.8 x 6.3 x 2.8 inch

• Net weight (2.2 lb = 1 kg)
• 1.6 kg / 3 lb 8.4 oz (3.524 lb)

• Source of data
• - - Data from my own collection

• Author
• Model page created by Jouko Laukkanen. See "Data change" for further contributors.
