• Country
• Great Britain (UK)

• Manufacturer / Brand
• Ferranti, GB

• Year
• 1927 ??

• Category
• Radio part (not a module)

• Radiomuseum.org ID
• 296517

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• - - No sound reproduction output.

• Material
• Bakelite case

• from Radiomuseum.org
• Model: Audio Frequency Transformer AF8 - Ferranti, GB

• Dimensions (WHD)
• 2.69 x 2.19 x 3.125 inch / 68 x 56 x 79 mm

• Notes

• Ratio:  3.5:1

  Inductance:  20/45 Henries





• Net weight (2.2 lb = 1 kg)
• 0 lb 15.5 oz (0.969 lb) / 0.440 kg

• Mentioned in
• - - Manufacturers Literature (Manufacturer's Datasheet)

• Author
• Model page created by Nick Hayward. See "Data change" for further contributors.
