MBT1089
Ferranti, GB
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Ferranti, GB
- Year
- 1962
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 115982
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 8
- Main principle
- Superheterodyne (common); ZF/IF 470 kHz
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Line / Batteries (any type) / 200-250 / 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: MBT1089 - Ferranti, GB
- Shape
- Portable set > 8 inch (also usable without mains)
- Notes
- Socket for external aerial. Released July 1962 price £14 13s 3d plus purchase tax. Same as Ekco model MBT414 with slightly different case.
- Price in first year of sale
- 18.00 GBP
- Source of data
- -- Collector info (Sammler)
- Literature/Schematics (1)
- - - Manufacturers Literature
- Author
- Model page created by Howard Craven. See "Data change" for further contributors.
