Vektorskop SSG-6
Filbig KG; München
- Country
- Germany
- Manufacturer / Brand
- Filbig KG; München
- Year
- 1980 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 170584
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Vektorskop SSG-6 - Filbig KG; München
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 120 x 210 x 280 mm / 4.7 x 8.3 x 11 inch
- Notes
- Filbig SSG-6 Audio Vektorskop;
L/R CRT Rasteranzeige, LED Signalindikatoren.
- Source of data
- - - Data from my own collection
- Author
- Model page created by a member from A. See "Data change" for further contributors.
