Digital multimeter 185

Digital multimeter 185; Fine Instruments (ID = 2264389) Equipment

Digital multimeter 185; Fine Instruments (ID = 2264390) Equipment

Digital multimeter 185; Fine Instruments (ID = 2264391) Equipment

Digital multimeter 185; Fine Instruments (ID = 2264392) Equipment

Digital multimeter 185; Fine Instruments (ID = 2264393) Equipment
Use red slider bar for more.
Digital multimeter 185; Fine Instruments (ID = 2264389) Equipment
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  South Korea
Manufacturer / Brand:  Fine Instruments Corporation (Finest); Bucheon--Si
Year: 1996 ?? Category: Service- or Lab Equipment
Valves / Tubes LM308
Semiconductors (the count is only for transistors) 4: 2N2222 2N2222 2N2222 2N2222 AD636 CD4066 TL061 TL062 unknown_IC unknown_IC 1N4148
Wave bands - without
Details
Power type and voltage Dry Batteries / 1 x 9 Volt
Loudspeaker -Loudspeaker incorporated, but system not known.
Power out
from Radiomuseum.org Model: Digital multimeter 185 - Fine Instruments Corporation
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Notes

Built-in buzzer

Literature/Schematics (1) -- Schematic

Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.



All listed radios etc. from Fine Instruments Corporation (Finest); Bucheon--Si
Here you find 5 models, 3 with images and 5 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
