• Year
  • 1950 ?
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 147407

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 21
  • Valves / Tubes
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 105 - 125 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: 13-G-33 - Firestone Tire & Rubber Co.
  • Shape
  • Tablemodel, with any shape - general.
  • Notes
  • Picture tube: 7JB4
  • Author
  • Model page created by Egon Penker. See "Data change" for further contributors.
