S7398-2 "Olympic"

S7398-2 'Olympic' ; Firestone Tire & (ID = 721402) Radio
S7398-2 'Olympic' ; Firestone Tire & (ID = 2360506) Radio S7398-2 'Olympic' ; Firestone Tire & (ID = 2360508) Radio
S7398-2 'Olympic' ; Firestone Tire & (ID = 2360510) Radio S7398-2 'Olympic' ; Firestone Tire & (ID = 2360511) Radio
S7398-2 'Olympic' ; Firestone Tire & (ID = 2360512) Radio S7398-2 'Olympic' ; Firestone Tire & (ID = 2360513) Radio
S7398-2 'Olympic' ; Firestone Tire & (ID = 2360514) Radio
Use red slider bar for more.
S7398-2 'Olympic' ; Firestone Tire & (ID = 2360506) Radio
Firestone Tire &: S7398-2 "Olympic" [Radio] ID = 2360506 1400x962
Select picture or schematic to display from thumbnails on the right and click for download.
For model S7398-2 "Olympic", Firestone Tire & Rubber Co. (Air Chief & Roamer, Airchief); Akron (OH):
Front view

Country:  United States of America (USA)
Manufacturer / Brand:  Firestone Tire & Rubber Co. (Air Chief & Roamer, Airchief); Akron (OH)
Year: 1942 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 12SK7 12SA7 12SK7 12SQ7 35L6GT 35Z4GT
Main principle Superhet with RF-stage; ZF/IF 456 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 110 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
Power out
from Radiomuseum.org Model: S7398-2 "Olympic" - Firestone Tire & Rubber Co.
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 14 x 8 x 8 inch / 356 x 203 x 203 mm
Notes Called the "Olympic" Built in loop antenna.
External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 14 = 1944 = before 1943
Literature/Schematics (1) Riders 14-5, 6
