90-C Serial #10001 to 19999
Fisher Radio; New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Fisher Radio; New York (NY)
- Year
- 1958 ?
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 170567
Service Manual
Sams Photofact Folders reference picture.
Service Manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 105 - 125 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: 90-C [Serial #10001 to 19999] - Fisher Radio; New York NY
- Shape
- Chassis only or for «building in»
- Notes
- The Fisher Model 90-C is an AC operated 4 Tube 7 Channel Audio Preamplifier.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 12-58, Set 424, Folder 7)
- Author
- Model page created by Egon Penker. See "Data change" for further contributors.
