• Country
• United States of America (USA)

• Manufacturer / Brand
• Fisher Radio; New York (NY)

• Year
• 1977

• Category
• Loudspeaker, headphone or earphone

• Radiomuseum.org ID
• 147999

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• 3 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Studio Standard STE1100 - Fisher Radio; New York NY

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 450 x 810 x 380 mm / 17.7 x 31.9 x 15 inch

• Notes
• 3-Weg-HiFi-Box mit 100 Watt an 8 Ohm. 30 - 20.000 Hz. 140 Liter Volumen.
  Bestückung: TT 305mm, MT 102mm, HT Horn, Frequenzweiche Übergänge bei 650/6.000 Hz.

• Net weight (2.2 lb = 1 kg)
• 38 kg / 83 lb 11.2 oz (83.7 lb)

• Source of data
• -- Original prospect or advert

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
