500-TX; Fisher Radio; New (ID = 1257738) Radio
Fisher Radio; New: 500-TX [Radio] ID = 1257738 933x499
Select picture or schematic to display from thumbnails on the right and click for download.
For model 500-TX, Fisher Radio; New York (NY):
Fisher 500TX Front View #1

Country:  United States of America (USA)
Manufacturer / Brand:  Fisher Radio; New York (NY)
Year: 1969/1970 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 54:
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: 500-TX - Fisher Radio; New York NY
Shape Chassis only or for «building in»
Dimensions (WHD) 430 x 130 x 370 mm / 16.9 x 5.1 x 14.6 inch
Notes Vollstereo, NF-Verstärker mit zwei Endstufen je 65 W (Sinus).
Vertrieb in D über ELAC.
Net weight (2.2 lb = 1 kg) 13.6 kg / 29 lb 15.3 oz (29.956 lb)
Price in first year of sale 2'995.00 DM
External source of data erb
Source of data Handbuch VDRG 1969/1970
