8 Transistor 2 Band NTR800
Use red slider bar for more.
Fleetwood brand?: 8 Transistor 2 Band NTR800 [Radio] ID = 1412997 550x516
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1961 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Semiconductors (the count is only for transistors) | 8: | ||||
|---|---|---|---|---|---|
| schematic requested | |||||
| Main principle | Superheterodyne (common); ZF/IF 455 kHz |
|---|---|
| Wave bands | Broadcast and Short Wave (SW). |
| Details | |
| Power type and voltage | Dry Batteries / 1 x 9 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.4 cm = 2.1 inch |
| Power out | |
| from Radiomuseum.org | Model: 8 Transistor 2 Band NTR800 - Fleetwood brand? |
| Material | Plastics (no bakelite or catalin) |
| Shape | Very small Portable or Pocket-Set (Handheld) < 8 inch. |
| Dimensions (WHD) | 126 x 75 x 29 mm / 5 x 3 x 1.1 inch |
| Notes | Similar to the models reported under Vista. |
| Source of data | - - Data from my own collection |
Model page created by Leo Brtna. See "Data change" for further contributors.
