• Year
  • 1982
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 142963

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • - without
  • Power type and voltage
  • Dry Batteries / 9 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Multimeter 8024 B - Fluke, John, Mfg. Co. Inc.;
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 85 x 180 x 45 mm / 3.3 x 7.1 x 1.8 inch
  • Notes
  • Fluke Vielfachmessgerät 8024B.
    Innenwiderstand 10 MOhm; Frequenzbereich: 45 Hz bis 5 kHz; Anzeigeart: LCD 3½, Anzeigenhöhe 11,6 mm; 9-V-Block-Batterie.
  • Net weight (2.2 lb = 1 kg)
  • 0.4 kg / 0 lb 14.1 oz (0.881 lb)
  • Price in first year of sale
  • 850.00 DM
  • Author
  • Model page created by Karlheinz Fischer. See "Data change" for further contributors.
