AC DC Differential Voltmeter 893A

AC DC Differential Voltmeter 893A; Fluke, John, Mfg. Co (ID = 1681667) Equipment AC DC Differential Voltmeter 893A; Fluke, John, Mfg. Co (ID = 1681668) Equipment
AC DC Differential Voltmeter 893A; Fluke, John, Mfg. Co (ID = 1681669) Equipment
Use red slider bar for more.
AC DC Differential Voltmeter 893A; Fluke, John, Mfg. Co (ID = 1681667) Equipment
Fluke, John, Mfg. Co: AC DC Differential Voltmeter 893A [Equipment] ID = 1681667 933x788
Select picture or schematic to display from thumbnails on the right and click for download.
For model AC DC Differential Voltmeter 893A, Fluke, John, Mfg. Co. Inc.; Everett (WA)

Country:  United States of America (USA)
Manufacturer / Brand:  Fluke, John, Mfg. Co. Inc.; Everett (WA)
Year: 1969 ? Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 50-500Hz, 115/230 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: AC DC Differential Voltmeter 893A - Fluke, John, Mfg. Co. Inc.;
Material Metal case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 8.5 x 7 x 12.5 inch / 216 x 178 x 318 mm
Notes

The Fluke 893A AC-DC Differential Voltmeter provides conventional or differential measurements of ac voltages from 1 mV to 1100 V and dc voltages from 10 uV to 1100 V.

Conventional (TVM) measurements are made with an accuracy of +/- 3% of the selected range to initially determine the magnitude of the measured voltage.The differential (NULL) mode is then used with an improved accuracy of up to 250% over that of the conventional mode to determine the exact value of the measured voltage,using the front panel Readout dials.

A rechargeable battery (Option 1) and recorder output (option 2) are available.

Net weight (2.2 lb = 1 kg) 12 lb (12 lb 0 oz) / 5.448 kg
