• Country
• United States of America (USA)

• Manufacturer / Brand
• Fluke, John, Mfg. Co. Inc.; Everett (WA)

• Year
• 1982

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 190237

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Line / Batteries (any type) / AC 90-132; 200-264 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Digital Multimeter 8012A - Fluke, John, Mfg. Co. Inc.;

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 188 x 61 x 248 mm / 7.4 x 2.4 x 9.8 inch

• Notes
• Digital Laboratory Multimeter. AC mains or storage battery (built in) operated.
  3 1/2 digits
  0.1% basic DC accuracy
  True RMS 45 Hz - 50 kHz

  DC-Voltage:
  200 mV
  2 V
  20 V
  200 V
  1000 V
  Input Impedance 10 Mohm on all VoltDC-ranges

  AC Voltage True-RMS:
  200 mV
  2 V
  20 V
  200 V
  750 V
  Input Impedance 10 Mohm in parallel with <100 pF

  Resistance: 0.001 ohm - 10000 Mohm
  2 ohm
  20 ohm
  200 ohm
  2 kohm *
  20 kohm
  200 kohm *
  2000 kohm
  20 Mohm *
  Diode Test range marked with *

  DC Current:
  200 µA
  2 mA
  20 mA
  200 mA
  2000 mA
  10 A

  AC Current:
  200 µA
  2 mA
  20 mA
  200 mA
  2000 mA
  10 A

  Conductance:
  2 mS
  20 µS
  200 nS


• Net weight (2.2 lb = 1 kg)
• 1.150 kg / 2 lb 8.5 oz (2.533 lb)

• Source of data
• - - Manufacturers Literature

• Author
• Model page created by Matti Kaki. See "Data change" for further contributors.
