Digital Multimeter 8022A

Fluke, John, Mfg. Co. Inc.; Everett (WA)

  • Year
  • 1979
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 191023

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 2
  • Semiconductors
  • Wave bands
  • - without
  • Power type and voltage
  • Batteries / addl. power jack / 9 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Digital Multimeter 8022A - Fluke, John, Mfg. Co. Inc.;
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 86 x 180 x 45 mm / 3.4 x 7.1 x 1.8 inch
  • Notes
  • 3 1/2 Digits. Auto-range, auto polarity. DC 200 mV-1000V. AC 200 mV-750V. AC/DC 2 mA-2A.200 Ohm-20 MOhm.
  • Net weight (2.2 lb = 1 kg)
  • 0.369 kg / 0 lb 13 oz (0.813 lb)
  • Source of data
  • - - Data from my own collection
  • Literature/Schematics (1)
  • -- Original-techn. papers.
