• Country
• United States of America (USA)

• Manufacturer / Brand
• Fluke, John, Mfg. Co. Inc.; Everett (WA)

• Year
• 1991

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 280927

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• none

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 100/120/220/240 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Digital Multimeter 8840A - Fluke, John, Mfg. Co. Inc.;

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 216 x 89 x 317 mm / 8.5 x 3.5 x 12.5 inch

• Notes

• The 8840A Digital Multimeter is high-performance 5½ digit instrument with fluorescent display.

  - Basic dc accuray of 0.005% for 1 year
  - 2-wire and 4-wire resistance measurement
  - Up to 100 readings per second
  - Closed-case calibration (no internal adjustments)
  - True RMS AC (Option -09)
  - IEEE-488 Interface Option



• Net weight (2.2 lb = 1 kg)
• 3.4 kg / 7 lb 7.8 oz (7.489 lb)

• Author
• Model page created by Pius Steiner. See "Data change" for further contributors.
