• Year
  • 1991
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 239418

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • - without
  • Power type and voltage
  • Dry Batteries / 1 x 9 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Multimeter Serie II 21 - Fluke, John, Mfg. Co. Inc.;
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 75 x 28 x 166 mm / 3 x 1.1 x 6.5 inch
  • Notes
  • Spannung: 300 mV bis 1000 VDC, 750 VAC;
    Strom: 10 A DC/AC;
    Widerstand: 0,1–32 MOhm;
    Durchgangsprüfung-Signalton: 4096 Hz;
    Automatische Bereichswahl, automatischer Festhalte-Betrieb;
    Diodenprüfung;
    Digital- und Balkenanzeige.

    See also Fluke Multimeter 73

  • Net weight (2.2 lb = 1 kg)
  • 0.3 kg / 0 lb 10.6 oz (0.661 lb)
  • Mentioned in
  • -- Original-techn. papers.
