Multimeter Serie II 75

• Country
• United States of America (USA)

• Manufacturer / Brand
• Fluke, John, Mfg. Co. Inc.; Everett (WA)

• Year
• 1991

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 239421

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Dry Batteries / 1 x 9 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Multimeter Serie II 75 - Fluke, John, Mfg. Co. Inc.;

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 75 x 28 x 166 mm / 3 x 1.1 x 6.5 inch

• Notes

• Spannung: 300 mV bis 1000 VDC, 750 VAC;
  Strom: 10 A DC/AC;
  Widerstand: 0,1–32 MOhm;
  Durchgangsprüfung-Signalton: 4096 Hz;
  Automatische Bereichswahl, automatischer Festhalte-Betrieb;
  Diodenprüfung;
  Digital- und Balkenanzeige.

  See also Fluke Multimeter 73

• Net weight (2.2 lb = 1 kg)
• 0.3 kg / 0 lb 10.6 oz (0.661 lb)

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
