RMS Differential Voltmeter 931B

Fluke, John, Mfg. Co. Inc.; Everett (WA)

  • Year
  • 1972 ?
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 116060

 Technical Specifications

  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 115; 230 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: RMS Differential Voltmeter 931B - Fluke, John, Mfg. Co. Inc.;
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 215 x 175 x 300 mm / 8.5 x 6.9 x 11.8 inch
  • Notes
  • The 931B is a full solid state RMS differential voltmeter. It measures RMS voltages from 5 Hz to 2 MHz over five ranges covering from 100 mV to 1000 V full scale. Accuracy as high as 0.02 % is given, depending upon the ranges.
  • Net weight (2.2 lb = 1 kg)
  • 2.5 kg / 5 lb 8.1 oz (5.507 lb)
  • Source of data
  • - - Data from my own collection
  • Author
  • Model page created by Emilio Ciardiello. See "Data change" for further contributors.
