Thermometer 54-ii

• Country
• United States of America (USA)

• Manufacturer / Brand
• Fluke, John, Mfg. Co. Inc.; Everett (WA)

• Year
• 2005 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 330519

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Dry Batteries / 3 x AA 1.5 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Various materials

• from Radiomuseum.org
• Model: Thermometer 54-ii - Fluke, John, Mfg. Co. Inc.;

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 3 x 6.4 x 1.1 inch / 76 x 163 x 28 mm

• Notes

• Fluke model 54-II dual input digital thermocouple indicator. Accepts type J, K, T, E, N, R and S thermocouples. Dual display.

• Net weight (2.2 lb = 1 kg)
• 0.280 kg / 0 lb 9.9 oz (0.617 lb)

• Author
• Model page created by Tom Seeger. See "Data change" for further contributors.
