AM-Receiver AR-1070TLI - AM 1002

Fujitsu Ten Limited (TEN); Kobe

  • Year
  • 1973 ??
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 283724

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 5 W (7 W max.)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: AM-Receiver AR-1070TLI - AM 1002 - Fujitsu Ten Limited TEN; Kobe
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 180 x 48 x 60 mm / 7.1 x 1.9 x 2.4 inch
  • Net weight (2.2 lb = 1 kg)
  • 0.5 kg / 1 lb 1.6 oz (1.101 lb)
  • Author
  • Model page created by Matthew Xenakis. See "Data change" for further contributors.
