Kurs Tischlautsprecher 1,5 VA

• Country
• Germany

• Manufacturer / Brand
• Funktechnik Leipzig, PGH; Leipzig

• Year
• 1957

• Category
• Loudspeaker, headphone or earphone

• Radiomuseum.org ID
• 83598

• • Brand: Stein

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10.5 cm = 4.1 inch

• Power out
• 1.5 W (unknown quality)

• Material
• Bakelite or Plastics (type unknown)

• from Radiomuseum.org
• Model: Kurs Tischlautsprecher 1,5 VA - Funktechnik Leipzig, PGH;

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 210 x 140 x 75 mm / 8.3 x 5.5 x 3 inch

• Notes

• PGH Funktechnik, "Kurs", Tischlautsprecher 1,5 VA;
  Frequenzbereich 120...12000 Hz ± 10 dB, 85 mm Manipermmagnet, 5000 Gauß, Luftspalt: 0,8 mm; Impedanzen: 5 Ohm, 15 Ohm oder 6 kOhm lieferbar; mit oder ohne eingebautem Lautstärkeregler.

• Net weight (2.2 lb = 1 kg)
• 0.9 kg / 1 lb 15.7 oz (1.982 lb)

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Mentioned in
• -- Original prospect or advert

• Literature/Schematics (1)
• Radio und Fernsehen (DDR) (1957, Heft 19, Seite 589)

• Author
• Model page created by Wolfgang Eckardt. See "Data change" for further contributors.
