• Year
  • 1949 ?
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 170045
    • Brand: FWE

 Technical Specifications

  • Number of Tubes
  • 2
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 120/220 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Megohmmeter 005 - Funkwerk Erfurt, VEB, RFT Ostd
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 235 x 180 x 170 mm / 9.3 x 7.1 x 6.7 inch
  • Notes
  • Messbereich 0,1...5000 MOhm in 4 Bereichen. Messung mit 150V ± 20% Gleichspannung an erdfreien Objekten. Das Anzeigeinstrument ist unmittelbar in MOhm geeicht.
    1961 Weiterentwicklung als Modell 005a.
  • Net weight (2.2 lb = 1 kg)
  • 2.5 kg / 5 lb 8.1 oz (5.507 lb)
  • Price in first year of sale
  • 490.00 Mark
  • Source of data
  • - - Manufacturers Literature
  • Mentioned in
  • -- Original prospect or advert (Angebotsliste Versorgungskontor, 2.Halbj.1962)
  • Literature/Schematics (1)
  • Funktechnik 1949/03 Anzeige
  • Author
  • Model page created by Wolfgang Lill. See "Data change" for further contributors.
