Bassreflexbox B4101
Funkwerk Kölleda, VEB, RFT, - vorm. Neutrowerk, Neutro-Werk (Ostd.)
- Country
- Germany
- Manufacturer / Brand
- Funkwerk Kölleda, VEB, RFT, - vorm. Neutrowerk, Neutro-Werk (Ostd.)
- Year
- 1984 ??
- Category
- Loudspeaker, headphone or earphone
- Radiomuseum.org ID
- 251691
- Wave bands
- - without
- Power type and voltage
- No Power needed
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Bassreflexbox B4101 - Funkwerk Kölleda, VEB, RFT, -
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 200 x 326 x 104 mm / 7.9 x 12.8 x 4.1 inch
- Notes
-
Bassreflexbox aus lackiertem MDF-Material, eingebautes Breitbandlautsprecherchassis: L2251; Impedanz: 8 Ω, Leistung max. 3 VA, Volumen: 3,5 Liter.
- Net weight (2.2 lb = 1 kg)
- 2.372 kg / 5 lb 3.6 oz (5.225 lb)
- Price in first year of sale
- 85.00 Mark
- Mentioned in
- Sortimentskatalog Elektroakustik (DDR, 1984)
- Author
- Model page created by Michael Mischke. See "Data change" for further contributors.
