For model Coronado 43-8190, Gamble-Skogmo, Inc.; Minneapolis, MN:
American Radio Design-Greg Mercurio

Country:  United States of America (USA)
Manufacturer / Brand:  Gamble-Skogmo, Inc.; Minneapolis, MN
Brand

Coronado
Year: 1947 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12SA7 12SK7 12SQ7 50L6GT 35Z5GT
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 105 - 125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out 0.6 W (unknown quality)
from Radiomuseum.org Model: Coronado 43-8190 - Gamble-Skogmo, Inc.;
Material Bakelite case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 9.5 x 7.5 x 6 inch / 241 x 191 x 152 mm
Notes Coronado "Racetrack" painted Bakelite tube radio, Model 43-8190.
The dial plaque loops around the front of the radio much like a race track, hence the nickname.
Collectors' prices
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 22, covering 1951
Mentioned in Table Top Radios Vol. 1 Stein 98
Literature/Schematics (1) Plastic Radios - The Antique Radio Collectors' Source Book
