94RA2-43-8230A

94RA2-43-8230A ; Gamble-Skogmo, Inc.; (ID = 245812) Radio

94RA2-43-8230A ; Gamble-Skogmo, Inc.; (ID = 245813) Radio
94RA2-43-8230A ; Gamble-Skogmo, Inc.; (ID = 245811) Radio
Use red slider bar for more.
94RA2-43-8230A ; Gamble-Skogmo, Inc.; (ID = 245811) Radio
Gamble-Skogmo, Inc.;: 94RA2-43-8230A [Radio] ID = 245811 440x262
Select picture or schematic to display from thumbnails on the right and click for download.
For model 94RA2-43-8230A, Gamble-Skogmo, Inc.; Minneapolis, MN

Country:  United States of America (USA)
Manufacturer / Brand:  Gamble-Skogmo, Inc.; Minneapolis, MN
Brand

Coronado
Year: 1952 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12BE6 12BD6 12AT6 50C5 35W4
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 105 - 125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out 0.8 W (unknown quality)
from Radiomuseum.org Model: 94RA2-43-8230A - Gamble-Skogmo, Inc.;
Material Bakelite case
Shape Tablemodel without push buttons, Mantel/Midget/Compact up to 14
Notes The 94RA2-43-8230A has a built in loop antenna. The number 94RA indicates first production year is 1949 (or 1948/49).
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 21, Copyright 1950
