C5D15 Ch= Series A

C5D15 Ch= Series A; Gamble-Skogmo, Inc.; (ID = 375879) Radio

C5D15 Ch= Series A; Gamble-Skogmo, Inc.; (ID = 375880) Radio
C5D15 Ch= Series A; Gamble-Skogmo, Inc.; (ID = 613388) Radio C5D15 Ch= Series A; Gamble-Skogmo, Inc.; (ID = 613398) Radio
C5D15 Ch= Series A; Gamble-Skogmo, Inc.; (ID = 613389) Radio C5D15 Ch= Series A; Gamble-Skogmo, Inc.; (ID = 613391) Radio
Use red slider bar for more.
C5D15 Ch= Series A; Gamble-Skogmo, Inc.; (ID = 613388) Radio
Gamble-Skogmo, Inc.;: C5D15 Ch= Series A [Radio] ID = 613388 800x573
Select picture or schematic to display from thumbnails on the right and click for download.
For model C5D15 Ch= Series A, Gamble-Skogmo, Inc.; Minneapolis, MN:
The Coronado C5D15 made for sale at Gamble department stores by the Belmont Radio Corporation (BRC). Photo courtesy of the Reverend Ronald Snethen.

Country:  United States of America (USA)
Manufacturer / Brand:  Gamble-Skogmo, Inc.; Minneapolis, MN
Brand

Coronado
Year: 1941 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12SA7 12SK7 12SQ7 50L6GT 35Z5GT
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 105-125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org Model: C5D15 Ch= Series A - Gamble-Skogmo, Inc.;
Material Bakelite case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 11 x 7 x 7.5 inch / 279 x 178 x 191 mm
Notes Built in loop antenna. Two knobs on either side at the bottom with a slide-rule dial at the top-front of the set.
Circuit diagram reference Rider's Perpetual, Volume 13 = 1942 and before

Model page created by Dirk Taekels. See "Data change" for further contributors.
