• Country
• United States of America (USA)

• Manufacturer / Brand
• Gamble-Skogmo, Inc.; Minneapolis, MN

• Year
• 1950 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 245229

• • Brand: Coronado

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 18

• Valves / Tubes
• 6BH6 6J6 6BA6 6BA6 6BA6 6AL5 12AU6 12AU6 19T8 25L6GT 12AU6 12SN7GT 12SN7GT 12SN7GT 50L6GT 50L6GT 1B3GT 7JP4

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• AC/DC-set / 105-125 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3.8 inch = 9.7 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: Coronado 43-8965 - Gamble-Skogmo, Inc.;

• Shape
• Tablemodel, low profile (big size).

• Notes

• AC or DC Operated TV Receiver

  Channels 2 thru 13

• Mentioned in
• Photofact Folder, Howard W. SAMS (Vol.9/50 Date 2-50 86-3 Set 86 Folder 3)

• Author
• Model page created by Friedrich Weber † 12.09.2014. See "Data change" for further contributors.
