Coronado 45RA1-43-7666A

Coronado 45RA1-43-7666A ; Gamble-Skogmo, Inc.; (ID = 472511) Radio

Coronado 45RA1-43-7666A ; Gamble-Skogmo, Inc.; (ID = 472512) Radio

Coronado 45RA1-43-7666A ; Gamble-Skogmo, Inc.; (ID = 472513) Radio

Coronado 45RA1-43-7666A ; Gamble-Skogmo, Inc.; (ID = 472514) Radio
Coronado 45RA1-43-7666A ; Gamble-Skogmo, Inc.; (ID = 472510) Radio
Use red slider bar for more.
Coronado 45RA1-43-7666A ; Gamble-Skogmo, Inc.; (ID = 472510) Radio
Gamble-Skogmo, Inc.;: Coronado 45RA1-43-7666A [Radio] ID = 472510 690x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Coronado 45RA1-43-7666A, Gamble-Skogmo, Inc.; Minneapolis, MN:
SAMS Photofact reference picture.

Country:  United States of America (USA)
Manufacturer / Brand:  Gamble-Skogmo, Inc.; Minneapolis, MN
Brand

Coronado
Year: 1953/1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6BA6 6BE6 6BA6 6AV6 6AQ5 6X4
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110-120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
Power out
from Radiomuseum.org Model: Coronado 45RA1-43-7666A - Gamble-Skogmo, Inc.;
Material Wooden case
Shape Console with any shape - in general
Notes The Coronado 45RA1-43-7666A made by Gamble-Skogmo, Inc. in Minneapolis is an AC operated combination phono-radio superheterodyne receiver with loop antenna.
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Date 3-54, set 232, folder 3)

Model page created by Ernst Erb. See "Data change" for further contributors.



All listed radios etc. from Gamble-Skogmo, Inc.; Minneapolis, MN
Here you find 597 models, 282 with images and 540 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
