AM FM Television Receiver 10TZ Series 10TZ4

AM FM Television Receiver 10TZ Series 10TZ4; Garod Radio Corp.; (ID = 1450763) TV Radio

AM FM Television Receiver 10TZ Series 10TZ4; Garod Radio Corp.; (ID = 1450764) TV Radio

AM FM Television Receiver 10TZ Series 10TZ4; Garod Radio Corp.; (ID = 1450766) TV Radio

AM FM Television Receiver 10TZ Series 10TZ4; Garod Radio Corp.; (ID = 1450767) TV Radio

AM FM Television Receiver 10TZ Series 10TZ4; Garod Radio Corp.; (ID = 1450769) TV Radio

AM FM Television Receiver 10TZ Series 10TZ4; Garod Radio Corp.; (ID = 1450770) TV Radio

AM FM Television Receiver 10TZ Series 10TZ4; Garod Radio Corp.; (ID = 1450771) TV Radio

AM FM Television Receiver 10TZ Series 10TZ4; Garod Radio Corp.; (ID = 1450772) TV Radio

AM FM Television Receiver 10TZ Series 10TZ4; Garod Radio Corp.; (ID = 1450773) TV Radio

AM FM Television Receiver 10TZ Series 10TZ4; Garod Radio Corp.; (ID = 1450774) TV Radio
AM FM Television Receiver 10TZ Series 10TZ4; Garod Radio Corp.; (ID = 1438210) TV Radio
Use red slider bar for more.
AM FM Television Receiver 10TZ Series 10TZ4; Garod Radio Corp.; (ID = 1438210) TV Radio
Garod Radio Corp.;: AM FM Television Receiver 10TZ Series 10TZ4 [TV Radio] ID = 1438210 933x692
Select picture or schematic to display from thumbnails on the right and click for download.
For model AM FM Television Receiver 10TZ Series 10TZ4, Garod Radio Corp.; Brooklyn (NY):
SAMS Photofact Vol.4/49 498-12 Set 60 Folder 12

Country:  United States of America (USA)
Manufacturer / Brand:  Garod Radio Corp.; Brooklyn (NY)
Year: 1949 ? Category: Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
Valves / Tubes 29: 6J6 6J6 6J6 6BA6 6BA6 6BA6 6BA6 6AL5 6AC7 6SN7GT 6BA6 6AU6 6AU6 6T8 6K6GT 6SN7GT 6AR5 6SN7GT 6AL5 6SN7GT 6BG6G 5V4G 1B3GT 6BA6 12AT7 6BE6 5U4G 5Y3GT 10BP4 or 10FP4
Main principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 inch = 25.4 cm
Power out
from Radiomuseum.org Model: AM FM Television Receiver 10TZ Series 10TZ4 - Garod Radio Corp.; Brooklyn NY
Material Wooden case
Shape Tablemodel, with any shape - general.
Notes

AM FM Television Receiver 10TZ4. Tuning ranges: AM 540 - 1650 kc, FM 88 - 108 Mc, TV channels 2 thru 13.

This set is equipped with a 10" picture tube, different types are possible.

Mentioned in Photofact Folder, Howard W. SAMS (Date 4/49, Set 60, Folder 12 (498-12))
Literature/Schematics (1) Rider's TV, 3-1

Model page created by Friedrich Weber † 12.09.2014. See "Data change" for further contributors.
