HiFi Music Centre GA200

Garrard Eng. & Mfg. Co. Ltd.; Swindon, England

Data
Forum
Pictures
Collections

  • Year
  • 1974 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 238617

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Details
  • Record Player (not changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 120 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 90 W (max.)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: HiFi Music Centre GA200 - Garrard Eng. & Mfg. Co. Ltd.;
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 756 x 182 x 412 mm / 29.8 x 7.2 x 16.2 inch
  • Notes

  • Garrard HiFi Music Centre Model GA200.
    AM-FM-LW Receiver, Cassette Player/Recorder and 2Speed (33,45 rpm) beltdriven 12" Turntable.
    Tone Arm with Shure cartridge and damped manual or automatic lowering system.
    Cassette player with auto-stop and tape type selection
    LW, MW & FM radio, with six pre-set stations on FM.
    Outputs for two front and two rear loudspeakers. 8 ohms impedance.
    90 watts total music power.
    Sockets for AM & FM aerials and Aux line input.
    Dust Cover.



  • Net weight (2.2 lb = 1 kg)
  • 19 kg / 41 lb 13.6 oz (41.85 lb)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
